Meltio unveils the Horizon software and new Laser Calibration System

Nov 14, 2022 | Press Releases

A disruptive laser metal deposition technology manufacturer – has today taken a giant step towards facilitating the use of its unique metal 3D printing solutions.

In its vision to accompany and be the reliable solution for industries around the world to adopt Meltio’s metal 3D printing solutions that reduces costs and improves manufacturing processes, the Spanish multinational has today presented two new innovations to increase the reliability of metal part manufacturing for creating accuracy parts: the Meltio Horizon software and new Laser Calibration System.

Both technological solutions developed by Meltio’s engineering team represent a further step in the company’s strategy to eliminate the barriers that have prevented metal additive manufacturing from having a significant presence in many industrial sectors. Meltio now becomes the perfect ally for these industries.

Meltio Horizon

Meltio Horizon is a proprietary toolpath generator software that ensures a fully tailored customer experience around its plug-and-play metal 3D printer, the Meltio M450, with its own unique features and custom-developed Meltio print and material profiles included.

The new software solution is tailored to use the laser wire metal deposition process with the Meltio M450. Up until now, Meltio users have been reliant on using 3rd party FFF slicers to prepare toolpaths for the Meltio M450.

In addition to traditional slicing parameters used in FFF software such as layer height, line width, print speed, and support materials, the new Meltio Horizon provides tailor-made access to Meltio’s laser-wire process, and material-specific parameters such as laser power, dual wire, and hot wire settings.

With the Meltio Horizon software, all of the material-related settings are directly in the slicing software, allowing for full control and just a single profile. This also allows us to create more specialized printing profiles, with the power to directly control the laser and hot wire on a “per slicing feature” basis, rather than being set for the full part.

This slicer is currently only compatible with the Meltio M450 metal 3D printer. For Meltio Engines (CNC and Robot Integration), the company is currently working on developing its open software ecosystem partnerships that allow the generation of 5 Axis G-Codes.

Key Features

  • Easy to use: Only Meltio’s laser-wire metal 3D printing process settings are available. Specific settings are explained to make the printing process go as smoothly as possible.
  • Cost calculation: Configure your printing cost model easily and have it calculate the cost per part in each project automatically.
  • Tailor-made to laser-wire: Made to order for Meltio’s wire-laser metal 3D printing process, it also includes built-in profiles for Meltio Materials.
  • Combined material profile: Previously divided between the printer and the slicer, everything is now in the slicer.

Laser Calibration System

In addition, Meltio has launched a new Laser Calibration System as an accessory (kit) to aid the reliability and ease of use of Meltio’s machines, ensuring a faster and more reliable print process to enhance user experience.

The Laser Calibration System allows Meltio users to calibrate Meltio’s multi-laser deposition head accurately and effortlessly on all three of its metal 3D printing solutions. The system consists of a laser alignment camera that has to be placed under the printhead as it allows for a clear view of the focus point of the lasers. The camera is controlled using a portable controller, which also comes included in the kit as well as a software specifically designed to filter the camera image and guide the user to focus each laser on the most optimal point.

The addition of this new kit is a major advance over the current state of general metal Additive Manufacturing (AM) solutions. Manual laser alignment remains possible but will require a very experienced operator to match the consistency of the laser alignment kit.

Meltio’s multi-laser metal 3D printing technology is based on the use of six lasers pointing to a mutual point to melt the welding wire that is fed through the center of the deposition head. The lasers generate a high concentration of energy, called meltpool, that melts the metal feedstock. As a result, welds beads are stacked precisely on top of one another.

The alignment of each laser is critical so they hit the exact point where the energy is concentrated, the misalignment of the lasers leads to energy inefficiency and defects on the 3D printed parts. The camera makes the calibration process easy to follow.

Key Features

  • Easy to use: Only Meltio’s laser-wire metal 3D printing process settings are available. Specific settings are explained to make the printing process go as smoothly as possible.
  • Cost calculation: Configure your printing cost model easily and have it calculate the cost per part in each project automatically.
  • Tailor-made to laser-wire: Made to order for Meltio’s wire-laser metal 3D printing process, it also includes built-in profiles for Meltio Materials.
  • Combined material profile: Previously divided between the printer and the slicer, everything is now in the slicer.
